PREDA

Aurorasound HomeEnglish > PREDA-English



PREDA





 alt



 PREDA is a solid state preamplifier with analog IN/OUT employing state-of-the-art transformer-type volume control system. The transformer uses super-reliable lead relays with 54-step, permitting precise setting with perfect Infrared remote control. Unlike conventional resister-type attenuator, the transformer system has no loss of signals, as heat, enabling precision volume control settings. Aurorasound’s newly developed discrete amp-module, having achieved ultra wideband and low distortion, balances input signal sources and adopt any type of output power amplifiers with excellent signal control.

 PREDA is developed with a completely new concept by adopting independent block for power supply, amplifiers, input and output modules for each L/R channels. A heavy duty solid aluminum chassis, extruded knobs, anti-vibration foot insulators are employed to achieve the highest-level musical performance, operation and aesthetics.   It is an ideal preamplifier as the center core of your audio system.

Apr.2014, Gain select switch is added on the bottom of chassis. This function is more minus 16 step down foe mid-night listening.

INPUT Line-level RCA Unbalance x4, XLR Balance x2
OUTPUT RCA Unbalance x1, XLR Balance x1 (#2HOT is convertible to #3 HOT with Global Phase Invert )
GAIN 10dB,     -6dB at Gain select SW on.
Frequency Response 5Hz . 100kHz -1.5dB
Total Harmonic Distortion 0.008%   A weighted
INPUT/OUTPUT Impedance Input 56kΩ /   Output 47Ω
Function 54Step Volume Contro,、 more -16step at Low Gaion mode,  L/R Balance Control、Mute、Display On/Off
Input Selector x6, Global Phase Reverse、Remote Control for those Functions
Size and Weight W 420 x D 330 x H 90mm、 10.8kg     AC100-120V  or  AC220-240V

preda-back



Supplemental Explanation

Block Diagram
System Block Diagram

Remote Controller

alt

PREDA



alt



1.Transformer-type Attenuator is an Energy Transfer Device

 A conventional resistor-type attenuator waste energy of reduced signal as heat. Since the current in a preamplifier is small, it does not give off high heat, however, attenuated signal is discharged in the air as heat. A transformer-type attenuator is an electric energy convertor without energy loss, therefore, it allows lossless signal level control. A typical transformer-type attenuator has only around 32 steps, but Aurorasound adopted 54 steps, which allows precise setting of volume level.



alt

トランス式アッテネータはエネルギー変換デバイス


 Transformer-type attenuator is available as a module. There is an issue associated with transformer-type attenuator. When CD Player and/or Power Amplifier having capacitors, which cut DC, are combined with the transformer-type attenuator, it generates a LC resonator causing undesirable impact on frequency response and phase alignment. PREDA eliminated such problems by adopting DC amplifiers before and after the transformer. As a result, it completely eliminates the influence of the capacitors.



alt



2.Highly-reliable Lead Relay is used for tap selection

Highly-reliable lead relay encapsulated in small glass tubes are of UK-based Pickering Manufacture. ON/OFF switching is
accomplished by an external magnetic field generated by current in the coil. Multiple lead relays are completely shielded by mu-metal to avoid mutual interferences.

2.タップ切り替えには高信頼性リードリレーを採用


3.Newly Developed Aurora-AMP Module

 Aurora-AMP Module is a discrete amplifier, capable of handling heavy load for high driving, up to 110dB open-loop gain. It has 12MHz gain-band width, THD+N of 0.0003%, through-rate of 28V/ usec, offering extremely high performance. The PCB is gold plated, without use of resist proces,s to avoid any coloration on sound. PREDA uses 6 units of this AMP module. This unit has become the core amplifier module of Aurorasound representing our company’s sound philosophy

Aurora-AMPモジュール
Aurora-AMP Module

4.Well-recognized power supply in VIDA is also used in PREDA, as well.

 This power supply is highly reputable for its super-low noise and high speed. PREDA is equipped with 2 independent power supply units for L/R channels. These power supplies are packaged in series to cancel unnecessary leakage flux from the transformers as shown in the picture below.

L/R独立電源部
L/R Independent Power Supply

5.Balanced Input has Instrumentation Amp Structure

 An Instrumentation AMP is used for the input of XLR balance signal. Output goes through Aurora-AMP module,which has high precision with balanced transfer circuit, allowing well balanced transmission of the signals. It requires a total of 4 modules in order to accomplish a completely balanced architecture including AMP and volume control for L/R channels. In addition, attenuation level in the HOT and COLD circuits, frequency responses, distortion must be identical in each channel. Otherwise, the differences will surface in the output stage. On the other hand,there are substantial merits such as immune to external noises and cable length. For these reasons, PREDA adopted balanced structure.


入力制御部
Input control module

alt



5.Balanced Input has Instrumentation Amp Structure



PREDA-TBSP

True Balanced Signal Path

  PREDA-TBSP is high grade version of PREDA, this is true balanced signal path. From input, amplification, autoformer attenuator, output buffer to output, all of signal path are true balanced configurations. This is almost double complexity of total circuitry compared to standard PREDA.  This TBSP system can eliminate common mode noise and get rid of ground noise influence, then make pure music signal and information transportation from source to power amplifier. Power supply unit is separate chassis. Four units of power transformer and regulators are completely independent for left/right channel and analog/digital control section. PREDA-TBSP is non compromise control center for real balanced signal path audio system. All functions are remote controlled by hand set.



alt





alt





alt







PREDA Review by FiHi News Magazine, UK,  HiFI Critic magzine, U.K.   Please check Download&Link page

alt    alt   alt    alt



"Stereo Times"  review  ----> Most Wanterd Compornents 2015, Click here



"6 moons" review  ---------> PREDA-TBSP  Click here





More information, please contact E-Mail  このメールアドレスは、スパムロボットから保護されています。アドレスを確認するにはJavaScriptを有効にしてください
